CURT 1-7/8-inch Hitch Ball for ATV/UTV/Lawn Tractor — Chrome, 2,000 lb Capacity

This compact hitch ball is engineered for utility: hot-forged steel construction, a chrome finish for weather resistance, and a shank sized to fit common ATV and lawn tractor tongues. It’s intended for light-duty towing tasks like hauling landscape trailers, gear haulers, and small campers—capacity always limited by the lowest-rated towing component in the system. Designed to use standard hardware, the CURT 40095 installs easily and provides a secure connection when torqued to specification.

How sturdy is this hitch ball for yard and trail towing?

The CURT 40095 is made from hot-forged steel and tested to industry safety specifications to deliver consistent strength for light-duty towing. Its 2,000-pound gross trailer weight rating suits small utility and landscape trailers encountered on farms, properties, and backroads.

• Hot-forged steel body for reliable tensile strength
• 2,000 lb gross trailer weight rating for small trailers
• Fine threads and supplied hex nut with lock washer for a secure mount

Will this hitch ball fit my ATV, UTV, or lawn tractor?

The ball has an industry-standard 1-7/8" diameter to mate with 1-7/8" trailer couplers, and the shank is 5/8" diameter by 1-3/4" long—dimensions commonly used on ATV tongues and lawn tractor hitch plates. If your vehicle’s hitch tongue accepts a 5/8" shank and the available thickness accommodates a 1-3/4" shank, the CURT 40095 will mount correctly.

• Ball diameter: 1-7/8" to match standard couplers
• Shank: 5/8" diameter x 1-3/4" length for common ATV/lawn tractor tongues
• Includes hex nut and helical lock washer for installation

How does the finish protect the hitch ball outdoors?

The CURT 40095 sports a chrome-plated finish that provides a corrosion-resistant barrier against moisture, dirt, and the elements you’ll face in yard or trail use. While the plating resists rust and simplifies cleaning, periodic inspection and basic maintenance will keep the surface performing longer in wet or salty conditions.

• Chrome plating for improved corrosion resistance
• Smooth surface reduces dirt buildup and eases cleaning
• Inspect seals, threads, and plating regularly for long life

What hardware and torque are required for secure installation?

The hitch ball ships with a zinc-plated hex nut and a helical lock washer to prevent loosening during use. The fine threads provide a tight fit; applying the manufacturer-recommended torque ensures the shank seats properly and delivers dependable holding strength under load.

• Supplied hex nut and helical lock washer included
• Fine-thread shank for enhanced clamping strength
• Follow torque specifications (90 lb.-ft. recommended) for safe installation

Who is this for: The CURT 40095 is aimed at owners of ATVs, UTVs, lawn tractors and compact utility vehicles who need a simple, durable hitch ball for light trailer work. It's well suited to landscapers, property owners, weekend campers with small teardrop trailers, and anyone who wants a reliable, easy-to-install towing solution for hauling gear, debris, or small loads—always ensure the rest of your towing setup matches the ball's ratings before use.
