Generic 30A RV/EV Outdoor Power Panel with 20A GFCI — Galvanized Steel, NEMA 3R Weatherproof

The Midwest U041CP is a weatherproof 30-amp RV/EV power outlet panel that includes a 20-amp GFCI for added ground-fault protection in outdoor installations.

This compact power box combines rugged construction with installer-friendly features to deliver reliable outdoor power where RVs, EV chargers, or auxiliary equipment need a protected feed. Built from galvanized steel and finished with a hard-wearing polyester coating, the enclosure is designed to resist corrosion and the elements while simplifying hookup through prewired components and versatile knockouts.

How does this panel stand up to outdoor conditions?

The enclosure is engineered for exterior use with weatherproof construction and corrosion-resistant materials. Its G90 galvanized steel and protective powder coat minimize rust and wear, while the door and seals keep internal components sheltered from rain and debris.

• G90 galvanized steel base to reduce corrosion
• Polyester powder coat finish resists chipping and fading
• NEMA 3R rating for outdoor protection against rain and snow
• Removable door with stay-open feature for secure access during service

What installation features speed up hookup and reduce errors?

The unit arrives factory assembled with all components prewired, which lowers installation time and minimizes wiring mistakes. Terminals accept both copper and aluminum conductors, and a variety of concentric knockouts give flexibility for conduit or raceway entries.

• Factory-wired components to shorten field wiring
• Terminals compatible with copper or aluminum wiring
• Multiple concentric knockouts to suit different conduit sizes
• Preinstalled Cu/Al equipment grounding lug for safe grounding

What safety and compliance features does this outlet box include?

Safety is prioritized with a dead-front design that prevents accidental contact with live parts and an integrated 20A GFCI to help protect against ground-faults for downstream loads. The assembly is ANSI certified and UL listed, meeting common regulatory expectations for commercial and recreational power equipment.

• 20-amp ground-fault circuit interrupter included for added protection
• Dead-front construction to prevent accidental live contact
• ANSI certification and UL listing for code-compliance confidence
• Factory-installed grounding lug for reliable earthing

Which applications and setups is this panel best suited for?

This panel is tailored for outdoor power distribution tasks where a 30A feed with a 20A protected outlet is useful—examples include RV pedestal power, modest EV charging support for inflatables or accessories, site equipment, and commercial outdoor outlets. Its durable construction makes it suitable for marinas, campgrounds, mobile work sites, and permanent property installations that face the elements.

• RV pedestals and campsite power stations
• Outdoor service outlets for small EV accessories or chargers
• Commercial sites requiring weatherproof, code-listed outlets
• Temporary or permanent outdoor equipment power points

Who is this for: Installers, property managers, and outdoor facilities planners who need a compact, code-compliant outdoor power solution will appreciate this Midwest U041CP panel. It fits situations that demand dependable, weather-resistant performance and flexible wiring options, while offering simplified installation and built-in safety features for commercial or heavy-duty recreational use.
