WnSEu Engine Lifting Bracket Kit 7100 — 4-piece, 5,500 lb Capacity, Heavy-Duty Steel

WnSEu Engine 7100 lifting bracket kit is a four-piece steel set designed to lift engines safely up to 5,500 pounds when used with load levelers and lifting slings.

This Engine 7100 kit provides a heavy-duty, compact solution for engine removal and installation during vehicle maintenance and repair. Built from high-strength steel and engineered for compatibility with load levelers and lifting slings, the set gives technicians and DIY mechanics a dependable attachment point that simplifies hoisting and positioning engines in tight engine bays.

How does the 7100 lifting bracket attach to an engine?

The brackets bolt directly to designated engine lifting points and distribute weight through a robust connection to your hoist or load leveler. Installation requires basic hand tools and follows standard lifting-point layouts on many automotive engines.

• Four-piece set matches common bolt patterns on engine blocks.
• High-quality steel construction resists bending under load.
• Works with standard load levelers, lifting slings, and chain hoists.

What safety and capacity limits should I be aware of?

The kit is rated for a maximum working load of 5,500 pounds; never exceed this capacity. Safe lifting also depends on using compatible load-rated equipment, inspecting hardware for wear, and following correct rigging procedures before each lift.

• Rated maximum load: 5,500 lb when used per instructions.
• Requires compatible load leveler or sling with equal or greater rating.
• Inspect brackets, bolts, and hoist connections before every lift.

Which tools and accessories are needed to use the kit effectively?

To mount the brackets you’ll typically need wrenches or sockets that fit your engine’s lift points, plus a certified load leveler, hoist, or lifting sling. Using the correct shackles and hardware with matching load ratings completes a safe rigging setup.

• Hand tools: sockets/wrenches that match engine mount bolts.
• Primary lifting gear: load leveler, chain hoist, or gantry crane.
• Connecting hardware: rated shackles or hooks and lifting slings.

How does the 7100 kit help during engine installation or removal?

These brackets provide secure, repeatable attachment points to control engine angle and height, making alignment into motor mounts easier and reducing strain on personnel. The four-piece design also helps balance awkward loads for safer maneuvering in confined spaces.

• Improves balance when using a load leveler to tilt engines.
• Frees up hands for guiding mounts and fasteners during installation.
• Compact brackets clear surrounding components in tight bays.

Who this is for: The WnSEu Engine 7100 lifting bracket kit is intended for automotive technicians, small repair shops, and competent DIYers who need a robust, repeatable lifting solution for engine removal and installation. If you already use a rated hoist or load leveler and want a steel bracket set designed to handle engines up to 5,500 lb, this kit delivers a straightforward, serviceable option that integrates with common lifting equipment. Always follow manufacturer guidance, inspect equipment before use, and pair the brackets with load-rated hoists and hardware for safe operation.
