Aeagle 12V Starter for Kohler Courage Engines — 130mm Field Case, 10‑Tooth Pinion, 1.0 kW PMDD

This heavy-duty replacement starter is engineered to deliver reliable cranking for single and twin Kohler Courage engines in the 7000 series and a wide range of residential and commercial lawn tractors and zero-turn mowers. Built with high-quality magnets or field coils, durable brushes and bushings, and a powerful 1.0 kW motor, the starter is intended as a direct-fit aftermarket solution where the longer 130mm field case and 10-tooth pinion match the machine’s original geometry.

Which engines and machines will this Aeagle starter work with?

The starter is compatible with many Kohler Courage engines (20–27 HP) and a long list of equipment models from Cub Cadet, Toro, Titan and New Holland. Check year and model fitment carefully: variations in field-case length and pinion teeth count mean not every part number is interchangeable.

• Kohler Courage twin SV710–SV840 families and 7000 series KT715–KT745
• Cub Cadet models: i1046, i1050, LT/LTX1046, SLT1550/1554, Z-Force and RZT series (multiple years)
• Toro and Titan: TimeCutter Z5020/Z5060, Titan Z5200/Z4800 and select Super Lawn/LX/GT tractors
• New Holland industrial: G4030/G4035/G4050 compatibility listed

How does the 130mm field case and 10T pinion affect fit and performance?

This version features a longer 130mm field case and a 10-tooth pinion; those dimensions affect mounting clearance and engagement with the ring gear. If your machine originally used a 108mm case with a 9T pinion, this starter will not be a correct swap without modifications.

• 130mm long field case needs matching mounting depth and spacers
• 10 teeth pinion must mesh properly with flywheel tooth count
• Rotation is counterclockwise (CCW) — confirm against your OEM starter
• Rated 12V, 1.0 kW power for robust initial torque

What are the electrical and mechanical specifications I should verify before buying?

Verify voltage, rotation direction, tooth count and physical length before ordering to avoid returns. This Aeagle starter is a PMDD type built for 12V electrical systems, CCW rotation, and a 10-tooth pinion configuration.

• Voltage: 12V — match your tractor/mower battery system
• Rotation: CCW (counterclockwise) — confirm OEM rotation
• Teeth: 10 — ensure ring gear compatibility
• Power: 1.0 kW PMDD starter designed for strong cranking torque

Which part numbers and replacements does this starter cover?

Aeagle’s unit replaces many OEM and aftermarket references so you can cross-check part numbers from your service manual. It covers several SAB and KH variants plus common OEM numbers found on Toro, Cub Cadet and other brands.

• Replaces: SAB0157, 32-098-08, 32-098-01-S and related 32-098 series numbers
• Also cross-references: 410-21069, 3209801, 5801N and other legacy codes
• Suitable for many Toro TimeCutter, Titan and Cub Cadet models listed in fitment
• Confirm the 130mm case / 10T pinion match before installation

Who is this for: Technicians, repair shops and DIY owners who need a high-torque, aftermarket replacement starter for Kohler Courage engines and compatible lawn and garden equipment. Choose this Aeagle starter when your machine calls for a 12V CCW unit with a 130mm field case and a 10-tooth pinion; if your OEM parts show a 108mm field case or 9T pinion, select the corresponding version instead. Always compare part numbers and physical dimensions before purchase to ensure a correct, trouble-free fit.

Features:

• Replaces numerous OEM part numbers including SAB0157, 32-098-01, 3209801, 410-21069 and others
• Compatible with many Cub Cadet, Toro, Titan and New Holland models (see list)
• Designed for Kohler Courage 7000 series engines (20–27 HP) and related applications
• Specifications: 12V, CCW rotation, 10 teeth, 1.0 kW, PMDD starter type
