EVIL ENERGY AN6 Braided Fuel Hose 20ft — Black Nylon-Braided, 750 PSI Working Pressure

EVIL ENERGY's 6AN braided fuel line is a 20-foot CPE inner, 304-steel-reinforced, nylon-braided AN6 hose built for high-pressure fuel, oil, and fluid routing.

This heavy-duty AN6 fuel hose combines a chemical- and heat-resistant CPE rubber core with a 304 stainless wire reinforcement and a protective nylon outer braid. Designed for automotive, racing, marine, and industrial uses, the 0.31" inner diameter hose supports a wide range of fluids and holds a maximum working pressure of 750 PSI with a burst threshold around 2,250 PSI. The hose ships in a 20-foot length and fits standard 6AN swivel hose ends; installation instructions are included for straightforward cutting and assembly.

How tough is this hose under pressure and heat?

The EVIL ENERGY 6AN braided fuel line is engineered to withstand continuous high-pressure service and elevated temperatures commonly encountered in performance applications. Its layered construction balances flexibility with strength to resist collapse and blowouts.

• Maximum working pressure: 750 PSI.
• Burst pressure: approximately 2,250 PSI.
• Operating temperature range: -22°F to 248°F (-30°C to 120°C).
• 304 stainless wire reinforcement prevents bulging and maintains hose shape.

Which fluids and systems can I safely use this hose for?

This AN6 hose is compatible with a broad set of automotive and industrial fluids, making it a versatile choice for fuel, oil, and fluid management tasks. It's suitable when you need a single hose to cover multiple service lines in tight engine bays or custom builds.

• Works with gasoline (including race gas), diesel, engine oil, transmission fluid, and hydraulic fluid.
• Suitable for fuel supply and return lines, oil feed, vacuum, and coolant bypasses.
• Compatible with turbo cooler lines and fuel gauge or sensor lines when properly routed.
• Not for use with fluids outside manufacturer chemical compatibility recommendations.

What are the size and installation considerations I should know?

The hose dimensions and connector compatibility determine fitment for AN6 systems; measure fittings and clearance before cutting. EVIL ENERGY supplies installation guidance so you can cut cleanly and assemble 6AN swivel hose ends securely.

• Inner diameter (ID): 0.31 inch; outer diameter (OD): 0.56 inch.
• Length: 20 feet, suitable for multiple runs or spare length for custom routing.
• Designed to accept 6AN swivel hose ends only—use the correct AN fittings and clamps.
• Includes basic installation instructions; use proper cutting tools and assembly practices.

How will the hose hold up to abrasion, chemicals, and daily use?

The outer nylon braid protects the hose from abrasion and chafing while providing a smooth finish for routing. The CPE inner layer resists many fuels and oils, and the stainless wire layer maintains structural integrity under repeated flexing.

• Nylon outer braid reduces abrasion and improves routing through tight spaces.
• CPE rubber inner tube resists common automotive fluids and fuels.
• 304 steel wire reinforcement prevents expansion and bursting under pressure.
• Suitable for both static and dynamic installations when properly secured.

Who this is for: This 20-foot EVIL ENERGY AN6 braided hose is aimed at mechanics, tuners, and DIY enthusiasts who need a reliable, multi-purpose line for fuel, oil, and fluid delivery in performance and custom applications. If you require a durable, high-pressure-capable hose that accepts standard 6AN fittings and offers long service life in demanding temperature ranges, this product is a practical choice.
